13-inch traversing drone
13-inch traversing drone
This 13-inch FPV drone is a powerful long-range quadcopter designed for heavy-duty FPV flying. It is equipped with a HAKRC F405 V2 flight controller and HK4214 80A ESC powered by 4214 400kv motors and 13-inch Gemfan propellers to ensure excellent stability and control. It is equipped with a Panda RC 5.8G 2.5W video transmitter and a Caddx H1 camera to provide high quality video at distances of 15-20 kilometers. Powered by 8S 10,000mAh batteries, the drone delivers 30-40 minutes of flight time and can carry a payload of 8-10 kilograms, making it ideal for demanding FPV applications and professional aerial operations.
This 13-inch FPV drone is a powerful long-range quadcopter designed for heavy-duty FPV flying. It is equipped with a HAKRC F405 V2 flight controller and HK4214 80A ESC powered by 4214 400kv motors and 13-inch Gemfan propellers to ensure excellent stability and control. It is equipped with a Panda RC 5.8G 2.5W video transmitter and a Caddx H1 camera to provide high quality video at distances of 15-20 kilometers. Powered by 8S 10,000mAh batteries, the drone delivers 30-40 minutes of flight time and can carry a payload of 8-10 kilograms, making it ideal for demanding FPV applications and professional aerial operations.
Description
Model |
MARK4 13-inch FPV |
Frame |
GEP-MK4-13 |
FC/ Flight Control |
HAKRC F405 V2 |
ESC/Electron Speed Control |
HK4214 80A |
MCU |
STM32F405RGT6 |
Gyroscope |
ICM-42688-P |
OSD/On Screen Display |
Betaflight OSD w/AT7456E chip |
VTX/Video Transmitter |
pandaRC 5.8G VTX 2.5W |
Camera |
Caddx H1 |
Antenna |
Momoda 5.8G RHCP SMA |
Motor |
CADDXFPV 4214 400kv |
Propeller |
Gemfan 1308-3 |
Weight |
1.55kg |
Receiver |
PNP/TBS NanoRX/GEPRC ELRS24/GEPRC ELRS |
Recommended battery |
Lipo 8S 10000mah |
Flight time |
30-40 minutes |
Flight speed |
140-160km/h |
flying distance |
15-20km |
flying distance(payload) |
7km |
carrying |
8-10kg |
Additional information
Performance parameters | parameters |
---|
